Real-fire Test of Domestic 15-meter Multi-caliber Rifle Bulletproof Vest

Body armor, also known as bullet avoidance vest, is a kind of protective equipment for individual soldiers, mainly used to resist the damage caused by bullets or shrapnel to the human body. Similar functions can be traced back to the cold weapon era, and armor made of various materials has the same use efficiency; modern body armor can be regarded as the “armor” of the hot weapon era to a certain extent; with the use of gunpowder, warfare The form has entered the era of hot weapons with higher speed and greater damage, and the requirements for protection are not the same. The body armor emerged during World War I.

The development of individual equipment in my country has been relatively slow. It used to be a feature of the People’s Liberation Army’s individual equipment for a long time. The People’s Liberation Army is affected by both the size of the army and its combat philosophy. It seems that it doesn’t care much about the construction of individual soldier protection, at least on the surface. When we admire the U.S. Kevlar bulletproof equipment, our individual equipment still has not got rid of the “five-flower tie” era elements. Today, a very small number of troops have come out equipped with new carrying equipment, and most of the troops still keep us. The military has consistently simple individual protection features.

On July 10, 2016, my country’s peacekeeping infantry battalion in South Sudan was attacked. A mortar shell hit a 92 wheeled infantry fighting vehicle with the initiation of a mortar, which eventually resulted in one death and six injuries. After the incident, according to the official details, a mortar shell penetrated the top of the infantry fighting vehicle and exploded in the vehicle. At that time, the infantry squad members were all inside the vehicle. The outside world responded to the 06 heavy body armor issued by Chinese peacekeeping officers and soldiers. The protection ability is highly evaluated.

So far, the domestic body armor made a big hit and began to enter the public eye. It turns out that we also have domestic bulletproof vests that are not weaker than similar international products.

06 style heavy body armor

The 06-style heavy-duty body armor adopts an integrated design developed by the international mainstream, combining the protective function with the traditional individual carrying gear. Made of soft and hard composite bullet-proof materials, it is composed of seven panels including throat protection, neck protection, shoulder protection, arm protection, rib protection, crotch protection, and traditional front and back protection. The protection area is large and the weight reaches nearly 8 About kilograms; is the most advanced model currently equipped by our army.

The 06-type heavy-duty body armor uses two types of bullet-proof inserts. The first is the insert formed by grinding and pressing of ultra-high molecular weight polyethylene; the second is the bullet-proof ceramic insert of silicon carbide or carbide ceramic. Ultra-high molecular weight polyethylene is the main material of our national defense bulletproof vests. It is a typical soft defense material. my country’s earliest 04B and 15-type armed police general bulletproof vests use this material; the ultra-high molecular weight polyethylene has a very high molecular weight, generally Between 5 million and 8 million, the strength is about 20% higher than that of ordinary aramid fiber materials, which is roughly 5-10 times higher than steel wire, but the density is only one-eighth of steel wire.

The bulletproof materials currently used by the US military are mainly aramid fiber materials. The biggest advantage of this material is that it is very soft, comfortable, and outstanding in high temperature resistance. Compared with my country’s UHMWPE materials, the strength of aramid fiber materials is much lower, which means that the anti-ballistic performance is also reduced. This is caused by the different design concepts of Chinese and American individual equipment.

The second type of bulletproof ceramic insert is a typical composite armor. It is composed of a total of four layers of materials. On the front and back of the bulletproof ceramics, a crack arrest layer made of aramid fiber material is added, and a layer of ultra-high molecular weight polyethylene material is added at the back to combine these four layers. Get up and press to shape, and finally spray paint.

CCTV’s military science program has done a program, using domestic 5.8mm steel core bombs and Type 53 7.62mm armor-piercing incendiary bombs for live ammunition testing at a distance of 15 meters. In the test, a 3.9 kg bulletproof steel plate and a 2.8 kg bulletproof ceramic insert plate are used for comparison; the traditional 5.8mm steel core bullet of the traditional bulletproof steel plate penetrates as soon as a bullet, while the ceramic plate achieves effective blocking and has the ability to resist the 5.8mm steel core bullet. . Because the 7.62mm armor-piercing incendiary bomb used in the second round had greater kinetic energy, only the ceramic plate was tested. The actual test results showed that the ceramic plate was only painted off and the warhead did not penetrate.

Based on the actual test of the above-mentioned CCTV program, my country’s latest bullet-proof ceramic inserts are capable of resisting 5.8mm steel core bombs and 7.62mm armor-piercing incendiary bombs at a distance of 15 meters. It is known for its strong penetrating power. I personally have the honor to witness a 70-meter breakdown of the core of a two-layer 04B body armor plus a police bulletproof shield; it is enough to prove its excellent protective performance.

Our country’s military bulletproof vests come from the Institute of Military Engineering and Technology under the System Engineering Research Institute of the Academy of Military Sciences, as well as the flame-retardant materials, camouflage materials, cold and warm materials used by our military, and food for individual soldiers in the field. The place. At present, my country, the Netherlands, South Korea, and the United States have become the world’s four major bulletproof material production countries. One workshop in my country can produce more than 200,000 pieces of body armor per year. Due to the traditional reputation of high quality and low price, my country’s multi-type body armor is currently exported to many The country has become a standard bulletproof vest.
